Automatic Pharmaceutical Equipment Ultrasonic Washing Machine 13 Kw 380V 50Hz

Brand Name : SED Pharma

Model Number : SED-80CXP-Z

Certification : CE

Place of Origin : China

MOQ : 1 Set

Price : Negotiable

Payment Terms : T/T,L/C,MoneyGram,Cash

Supply Ability : 30 Sets per month

Delivery Time : 50-60 Days after receiving the deposit

Packaging Details : Wooden Case

Name : Automatic Pharmaceutical Machinery Equipment Ultrasonic Washing Machine

Speed : 300 bottles/min

Power Consumption : 12.5 kw

Purified Water Consumption : ~1.5 m³/h @ 0.15–0.18 MPa

Compressed Air Consumption : ~45 m³/h @ 0.6–0.8 MPa

Dimension(L*W*H) : 2050×2050×1450 mm (L×W×H)

Machine Weight : Approx. 2200 kg

Keywords : Ultrasonic Washing Machine Automatic bottle Washing Machine

Contact Now

Automatic Pharmaceutical Machinery Equipment Ultrasonic Washing Machine​



Product Overview of Washing Machine

The Ultrasonic Washing Machine​ is a high-efficiency vertical ultrasonic cleaning machine designed for cleaning ampoules, vials, and other pharmaceutical containers. It features a rotating drum structure with robotic gripper flipping and ultrasonic pre-cleaning, providing "three-water three-air" alternating jet washing to ensure thorough cleaning in an inverted position. Constructed with 304 stainless steel and non-toxic corrosion-resistant materials, it meets GMP standards and is ideal for pharmaceutical and biotech industries requiring high cleanliness levels.



Product Parameters of Washing Machine

Model
 SED-80CXP-Z
Compatible Containers
 Ampoules, vials, etc.
Capacity Up to 300 bottles/min
Power Consumption 12.5kW
Purified Water Consumption ~1.5 m³/h @ 0.15–0.18 MPa
Compressed Air Consumption ~45 m³/h @ 0.6–0.8 MPa
Machine Weight Approx. 2200 kg
Dimensions 2050×2050×1450 mm (L×W×H)


Operational Process
Conveyor feeding → Ultrasonic immersion cleaning (~1 minute) → Screw lifting → Robotic gripper flipping 180° (mouth downward) → Alternating triple water & air jet tracking cleaning → Robotic flipping upright → Synchronous belt discharge to sterilizing tunnel


Features of Washing Machine​

  • Dual Cleaning Action: Ultrasonic pre-wash + triple water/air alternating spray for complete residue removal

  • Robotic Gripper System: Stable clamping and precise flipping to prevent container damage

  • Enclosed Clean Design: Fully enclosed workspace with transparent PC glass to prevent contamination

  • Intelligent Line Control: Interfaces with sterilizing tunnels and filling machines; auto-stop when full to prevent jams

  • Multi-level Safety: Water level control, pressure display, constant temperature control, and dry-run protection

  • Premium Components: Siemens PLC & HMI, Schneider frequency converter, ABB main motor for reliable operation



Application of Washing Machine

Food, Chemical, Pharmaceutical, etc.
